4-1-3 Offline Operations

Group Name
Programming Connect line
Save program
Retrieve program
Change display
Search
I/O comment
Instr comment
Block comment
Edit ladder
Edit comments
Retrieve
comments
Memory usage
Clear memory
Check program
Function code Mnemonic
17 ASFT
18 TKY
19 MCMP
47 RXD
48 TXD
60 CMPL
61 INI
62 PRV
63 CTBL
If unsupported addresses are set in the program for operands or set values,
error messages will be displayed and the values will not be accepted.
The following operations are possible when not connected online to the PC.
Draws a line between two ladder diagram objects.
Writes all or part of the user program developed in the system work area to the
data disk.
Retrieves all or part of the user program stored on a data disk to the system
work area.
Specifies the display modes for the user program.
Searches for instructions including specified operands. An address from which
the search is to be started can be specified
Creates I/O comments corresponding to bit addresses in the Ladder With
Comments mode. In addition, reads (searches) and edits the program for
comments.
Creates and edits instruction comments for output instructions in the Ladder
With Comments mode. (C-series PCs only)
Creates, reads (searches), and edits block comment in the Ladder With
Comments mode.
Edits ladder diagrams using the following:
• Moving specified instruction blocks
• Copying specified instruction blocks
• Deleting specified instruction blocks
Displays I/O comments simultaneously to write, edit, and search for specified
comments.
Retrieves comments from the program stored on a data disk. The I/O comments
are read to the system work area. Instruction comments (C-series PCs only)
and block comments are copied to the currently displayed program.
Displays the used capacity of the user program memory, the number of
comments used, and the available capacity of the internal memory.
Clears the user program memory. The starting address for clearing can be
specified. The comment memory can also be cleared.
Checks whether the user program contains syntax errors. The check can be
performed in three levels.
Function code Mnemonic
64 SPED
65 PULS
66 SCL
67 BCNT
68 BCMP
69 STIM
87 DSW
88 7SEG
89 INT
Description
Section 4-1
