- Page 1 Instruction Manual DIGITAL PRESSURE GAUGE Model No. : UT-1301 Ex. Flameproof / M S or S S Box www.utplindia.in sales@utplindia.in +91 7046223333 , 9427301436...
- Page 2 All configurations and calibrations by front keys only Uses world class sensor diaphragms. Unitech’s UT-1301 is an Ultra Low Power Microprocessor controlled, accurate and versatile Digital Pressure Measuring Instruments. And display the same to the resolution of full 5 / 6 digits in an integrated numeric / alphanumeric LCD structure.
-
Page 3: Measuring Vacuum
The sensor is rated for 125% of the specified range. If pressure exceeds beyond 125% of the specified pressure, the sensor may burst. The Digital -H1- Pressure Gauge UT-1301 will read “ ” [OVERRANGE] if pressure exceeds the specified range. -
Page 4: Units Button
It's is also good practice to check zero as your final reading too, as the unit should return to perfect zero reading. The Digital Pressure Gauge UT-1301 can zero or tare from approx ± 10% of the stored memory zero count. This is because if the Digital Pressure... -
Page 5: Specification
DIGITAL PRESSURE GAUGE UT - 1301 SPECIFICATION The UT-1301 must be exercised and re-zeroed whenever exposed to significant environmental conditions to achieve these specifications. To exercise the gauge, cycle the Digital Gauge between zero and pressure of interest. A properly exercised gauge will return to perfect zero reading. - Page 6 NORMAL USE OF UT-1301 The Digital Gauge UT-1301 is simple to use. Switch on the instrument it ill check various parameters like memory, calibration. After self check it will display the pressure along with unit. If the pressure port is in open condition ideally it should show 00000 reading if not press ZERO for 2 sec.
- Page 7 On/Off -.0001 Min/Max 0 TO 400 BAR UNITS CLEAR ZERO Min/Max Units UT-1301 www.unitechinstrument.com Zero Clear There are five keys in the front of Digi Gauge. The functions of the keys are: On/Off Key: To switch on or off the instrument.
- Page 8 DIGITAL PRESSURE GAUGE UT - 1301 Factory : Unitech Technocrats Pvt. Ltd. Plot No. 78/1/Z/3 Makarpura GIDC, Nr.Vadsar Bridge, Opp. Gaytri Mandir, Vadodara-390010. CIN NO. : U29221GJ2015PTC082824. Authorised Dealer Inquiry : Phone No. : +91-7046223333 / 00 Cell No. : +91-9427301436 / 9106727130 Email-Id : sales@utplindia.in / info@utplindia.in...
