INSTRUCTION MANUAL
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR
CONTROLLER / SCANNER / DATALOGGER
*
MODEL NO. : UT-30X, UT-100X
4-CHANNEL
8-CHANNEL
12-CHANNEL
16-CHANNEL
FLP : 8-CHANNEL
FLP : 4-CHANNEL
* NOTE : X= NO. OF CHANNEL MULTIPLE OF FOUR.
@
www.utplindia.in
sales@utplindia.in
+91 7046223333 , 9427301436
www
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Unitech UT-30X
Summary of Contents for Unitech UT-30X
- Page 1 INSTRUCTION MANUAL MULTI CHANNEL UNIVERSAL PROCESS INDICATOR CONTROLLER / SCANNER / DATALOGGER MODEL NO. : UT-30X, UT-100X 4-CHANNEL 8-CHANNEL 12-CHANNEL 16-CHANNEL FLP : 8-CHANNEL FLP : 4-CHANNEL * NOTE : X= NO. OF CHANNEL MULTIPLE OF FOUR. www.utplindia.in sales@utplindia.in +91 7046223333 , 9427301436...
- Page 2 230 15% VAC - a switch, fuse (1/2A, 250V) or a circuit breaker. The above items should be installed together with UT-30X,100X for the products electrical protection. The switch, Fuse or circuit-breaker should be located close to the controller, within easy reach operator.
-
Page 3: Table Of Contents
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X CONTENTS OVERVIEW ....................INTRODUCTION ..................NSTALLATION ........................................MOUNTING ....................EXTERNAL DIMENSION ....................TECHNICAL SPECIFICATIONS ....................WIRING DIAGRAM PROGRAMMING ..................................OPERATION INTERFACE ..............MODE ACCESS FLOW CHART OPERATIONAL MODES ................... -
Page 4: Overview
Parameters can also be hidden to user to prevent improper configuration of the unit Mount Anywhere The UT-30X, 100X product group is Process control instruments that must be panel mounted. The wiring terminals must be provided. The UT-30X,100X is environmentally hardened and, if suitably handled, can be mounted virtually anywhere in plant or factory;... -
Page 5: Technical Specifications
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Technical Specifications TECHNICAL SPECIFICATIONS K, J, R, S, T, E Pt-100, Pt-1000, Cu-53 [2 wire, 3 wire] Type of Input Linear : 4 ~20mA DC, 0~20mA DC, 0 ~5 Amp AC CURRENT [Analog]... -
Page 6: Wiring Diagram
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Terminal Schematic Wiring Diagram Input Selection NOTE : IN THIS UNIT , WE CAN SELECT INPUT TO INDIVIDUAL CHANNEL. THIS CAN BE DONE BY BOTH HARDWARE AS WELL AS BY PROGRAMMING. HARDWARE INPUT SELECTION IS AS BELOW:... - Page 7 MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Terminal Wiring Diagram CH:1 INPUT Transmi er Transmi er Shor ng 1 2 3 1 2 3 3 4 30 26 3 4 30 26 J / K / R / S / T / E...
-
Page 8: Programming
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X PROGRAMMING Operation Interface FRONT VIEW www.utplindia.in CH:1 PV Display CH-1 Low LED CH-1 High LED CH:2 PV Display CH-2 High LED CH-2 Low LED CH:3 PV Display CH-3 High LED CH-3 Low LED... -
Page 9: Mode Access Flow Chart
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Mode Access Flow Chart. Setup Configuration Change Calibration Mode Mode Mode Password Mode Normal Mode CH:1 & CH:2 Mode Selection Press & key to enter into the Programming mode from Normal mode... -
Page 10: Operational Modes
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X OPERATIONAL MODES Configuration Mode ‘Configuration Mode’ will shown by pressing & key in the Normal mode.. Display Parameter Range / Values CONFIGURATION MODE PASSWORD Range : Values between Password for Config. Mode Parameters... - Page 11 MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Continue Configuration Mode... Display Parameter Range / Values ALARM 1 HIGH ACTION TYPE Values : : Active in Low Change the type by key. : Active in High L-ON : SV+Hyst H-ON :...
-
Page 12: Setup Mode
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Setup Mode ‘Setup Mode’ Mode will shown by pressing key, after Mode display. Display Parameter Range / Values SETUP MODE PASSWORD Range : Values between Password for Setup Mode Parameters Scroll the digit by key, Increase by key. - Page 13 MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Continue Setup Mode... Display Parameter Range / Values Range : Values between CH:3 ZERO or LOW DISPLAY VALUE [LINEAR I/P] (According to Decimal point) Display value at Low Input applied. Scroll the digit by key, Increase by key.
-
Page 14: Calibration Mode
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Calibration Mode ‘Calibration Mode’ Mode will shown by pressing key, after Mode display. Display Range / Values Parameter CALIBRATION MODE PASSWORD Range : Values between Password for Calibration Mode Parameters Scroll the digit by key, Increase by key. -
Page 15: Change Password Mode
MULTI CHANNEL UNIVERSAL PROCESS INDICATOR UT-30X CONTROLLER/SCANNER/DATALOGGER UT-100X Change Password Mode ‘Change Password Mode’ Mode will shown by pressing key, after Mode display. Display Range / Values Parameter CHANGE PASSWORD MODE PASSWORD Range : Values between Password for Change Password Mode. -
Page 16: Communication [Modbus Rtu] Protocol
DATA+ RS-485 BUS Ethernet DATA- CONVERTER www.utplindia.in UNITECH TECHNOCRATS PVT LTD All content are subject to change without notice FACTORY:- 78/1/Z/3-Makarpura G I D C .., due to continuous improvements. +91 7046223333 , 9427301436 N/R Vadasar Bridge. /p-Gayatri emple Doc.
