GALEOBT
Backlit Bluetooth keypad and remote electronics

1] PRODUCT PRESENTATION

GALEOBT is an innovative surface mount keypad combining sleek and stylish aesthetics
with robust security. With a remote electronic controller and vandal-resistant body, this
keypad minimises the risk of the system being disabled through tampering. GALEOBT
is Bluetooth-enabled, and its free iOS or Android app makes programming easier than
ever. With a simple and intuitive interface, you can quickly set up all the key parameters
directly from your smartphone.
3 relay outputs
Backlit keys
100 user codes
Finish: Zamak®
Technology: Bluetooth
Free voltage
Operating voltage:
- 12V to 24V DC
- 24V to 48V DC
Consumption: With the 3 relays
activated and keypad lit
12 V 24 V 48 V
AC 166 mA 82 mA -
DC
195 mA 105 mA 54 mA

2] PACKAGE CONTENTS

GALEO ®
(M4x10) T20
Mounting
Screw
plate Varistor Torx® Torx®
cap
(keypad)
screw spanner
1 1 1 1 1

3] SPECIFICATIONS

Feature Description
Indoor/outdoor use (IP64) Keypad and keys polished in heavy duty Zamak
is high resistant to vandalism
Intuitive programming 100 user codes customisable by each user
Ergonomic Audible and visual feedback
Default programming There is no master code in the factory setting (5 digits)
Two programming options Use the TMGALEO keypad or the app to programme the remote
electronics
2
IP64 WEEE & RoHS CE Certification
IK10 -25°C to 70°C UKCA Certification
(x4)
Mounting
Sealed Sealed
(M4x30)
Plastic plate
cap cap
Mounting
(remote
anchor
screw
Ø20mm Ø25mm
electronics)
4 4 2 2 1
cast alloy and
®
EN EN

4] WIRING AND CONNECTIONS

The memory can be reset
with the P1 jumper. Switch
off the power. Place the
jumper on P1 and switch
the power back on to reset
the memory.
P2 jumper allows to the user to
modify its own PIN code.
To enable this feature put the
jumper on.
Recommended power supplies
ADC335
Outputs
V
INPUT
V
NC
DOOR 1 C
NO
NC
DOOR 2
C
NO
NC
DOOR 3 C
NO
PB1
Push
M
button
PB2
PX
Clock H
H
+
Keypad
-
TMGALEO
E
GALEOBT
Backlit Bluetooth keypad and remote electronics
ADC612S
Wiring table
Input voltage 12V to 24VAC or 12V to 48VDC
Input voltage 12V to 24VAC or 12V to 48VDC
N/C contact relay 1
Common relay 1
Request-to-exit inputs
N/O contact relay 1
PB1 request-to-leave input activates
N/C contact relay 2 relay 1.
PB2 Request-to-exit input activates
Common relay 2
relay 2.
N/O contact relay 2
N/C contact relay 3
Mode and programming time are
programmable.
Common relay 3
N/O contact relay 3
The H input can be used with a time
Request-to-exit input relay 1
switch to allow free access after any
Common of inputs
button on the code
Request-to-exit input relay 2
When the contact between the right
Not used Not used
'H' and 'M' is open, the request for
Not used Not used
access is disabled. When the contact is
Timer Contact
closed, you can press any key to open
relay 1.
White wire from keypad
Brown wire from keypad
Green or Blue wire (illumination)
P2 P1
BP1 BP2
PB1 PB2
