- Page 1 SMITH FOR SUPER GYM 1 OWNER’S MANUAL Model No. SMITH FOR SG1 Fitness Authority Industrial Co., LTD. No. 15, Xiangxue Rd., Dali Dist., MK20769 Taichung City 41275, Taiwan. ATTAIN FITNESS...
-
Page 2: Important Safety Notes
7. Make certain all cables are seated within the pulleys before every use. 8. Exercise with care to avoid injury. 9. If you are unsure about the proper use of the ATTAIN FITNESS SMITH FOR SG1, call your local ATTAIN FITNESS dealer or our customer service department. - Page 3 Gym Placement Planner 84.4” 65.2” HEIGHT 83.3" Important Notes and Tips: Recommended Tools 1. Do not tighten bolts until instructed. for Assembly 2. Two people are required for the safe assembly of this product. 3. Use window cleaner or water to assist with sliding roller pads on to tubes.
- Page 4 SMITH FOR SG1 PARTS LIST 1 NOTE: If you are missing a listed part, it likely has been pre-installed in our factory for quality control purposes. Please con�nue with assembly. *Parts images are not to scale. (903) BASE (904) TOP...
- Page 5 STEP 1 1. Attach two Upright Frames (901) to two Base & Top Frames (903 & 904) using eight 1/2” X 3” Hex Bolts (922), sixteen 1/2“ Washers (929) and eight 1/2” Nylon Nuts (931). 2. Attach two Guide Rods (902) to two Base & Top Frames (903 & 904) using six 5/16” X 1/4”...
- Page 6 STEP 2 1. Attach Upright Frame (901) to Left Base & Top Frame (2L & 15L) using two 1/2” X 2-3/4” Hex Bolts (923), two 1/2“ X 1” Hex Threaded Bolts (925), six 1/2” Washers (929) and two 1/2“ Nylon Nuts (931). 2.
- Page 7 STEP 3 1. Hook the Barbell Bar (910) into holes #5 in the Upright Frame (901). Be certain the bolt tabs welded to the Vertical Bearing Housings (909) are to the inside of the bolt tabs on the Barbell Bar (910) as shown in drawing, then attach the Barbell Bar (910) to the Vertical Bearing Housings (909) using four 3/8"...
- Page 8 EXPLODED 905L 906R...
-
Page 9: Parts Chart
PARTS CHART NO. DESCRIPTION QTY. UPRIGHT FRAME GUIDE ROD BASE FRAME TOP FRAME 905L LEFT SAFETY CATCH 906R RIGHT SAFETY CATCH HOOK PLATE SAFETY SPOTTER VERTICAL BEARING HOUSING BARBELL BAR OLYMPIC WEIGHT SLEEVE 905L 906R SPRING OLYMPIC SPRING CLIP BIG WASHER BEARING BEARING BEARING... - Page 10 Guide Rods (6). 5. Enjoy many years of a Fit Lifestyle. Thank you for purchasing the ATTAIN FITNESS SMITH FOR SUPER GYM 1! If you have questions or comments, please contact our customer service department at +1 877-551-7484 and info@attainfitnessusa.com.
