- Page 1 H841 LAT & LOW PULL ATTACHMENT FOR H840 POWER RACK OWNER’S MANUAL Model No. H841 Fitness Authority Industrial Co., LTD. 7180-1 No. 15, Xiangxue Rd., Dali Dist., Taichung City 41275, Taiwan. ATTAIN FITNESS...
- Page 2 The recommended free area in at least 60cm on every side. 16. If you are unsure about the proper use of the ATTAIN FITNESS H841 LAT & LOW PULL ATTACHMENT FOR POWER RACK, call your local ATTAIN FITNESS dealer or our customer service department.
- Page 3 Gym Placement Planner 34.2" HEIGHT 47" 82.5" Important Notes and Tips: Recommended Tools 1. Do not tighten bolts until instructed. for Assembly 2. Two people are required for the safe assembly of this product. Ratchet 3. Use window cleaner or water to assist with sliding roller pads on to tubes.
- Page 4 H841 Assembly PARTS LIST 1 NOTE: If you are missing a listed part, it likely has been pre-installed in our factory for quality control purposes. Please con�nue with assembly. *Parts images are not to scale. (54) 75mm X 170mm LINK PLATE...
- Page 5 ASSEMBLY Do NOT tighten any bolt until instructed. 1. Attach Base Frame (51) to Rear Frame of Power rack, using two 1/2" X 4" Hex Bolts (75), one Link Plate (55) and two 1/2" Nylon Nuts (82). Attach three 45 mm X 75 mm Cap (62) to Base Frame (51). 2.
-
Page 6: Cable Installation
CABLE INSTALLATION (74A) Top Cable Assemble cables and pulleys simultaneously. Route threaded end of Top Cable (74A) into slot in front of Top Frame (52) and out of slot in rear of Top Frame (52). Attach Pulleys in bracket at these slots with cable running above as shown in Fig 2 and Fig 3 Route cable down and around top pulley in Double Pulley Block (56) as shown in Fig 4. -
Page 7: Exploded View
EXPLODED VIEW... -
Page 8: Parts Chart
PARTS CHART NO. DESCRIPTION QTY. BASE FRAME TOP FRAME GUIDE ROD 81.8" 75mm X 170mm LINK PLATE 50mm X 170mm LINK PLATE DOUBLE PULLEY BLOCK LAT BAR HOLDER TWO WAY TOP PLATE LAT BAR LOW ROW BAR STACK SPACER 24" 75mm X 45mm CAP 45mm X 75mm PLUG PULLEY... - Page 9 Guide Rods (53). Enjoy many years of a Fit Lifestyle. Thank you for purchasing the ATTAIN FITNESS H841 LAT & LOW PULL ATTACHMENT FOR H840 POWER RACK! If you have any questions or comments, please contact our customer service department at +1 877-551-7484 and info@attainfitnessusa.com.
