Hardware Installation and Reference Guide
1. Front Panel
Figure 1-2 shows the rear panel of the RG-S7810C-X.
Figure 1-2 Front Panel of the RG-S7810C-X
Note: (1)
(2)
2. LEDs
LED
Supervisor module 1
status
System status LED
Service module slot
Panel
Identificati
on
CM1
(3)
(4)
Status Description
Off The module is powered off.
Solid red The module is faulty.
Blinking The module is being initialized. If the LED
green blinks continuously, a fault occurs.
Solid The module has been initialized and is
green working.
4
Product Overview
Cable management bracket
Anti-static wrist strap socket
