Altronix TROVE T2PDK75F16S Installation Manual

Access & Power Integration
Altronix/PDK Kits
Models Include:
T2PDK75F16S
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TPD2 Altronix/PDK backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (2) ACMS8 - Dual Input Fused Access Power Controllers
- (1) VR6 - Voltage Regulator
- (1) PD8UL - Fused Power Distribution Module
T2PDK77F24S
24 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TPD2 Altronix/PDK backplane
- (2) eFlow104NB - Power Supply/Chargers
- (2) ACMS12 - Dual Input Fused Access Power Controllers
- (2) VR6 - Voltage Regulators
- (2) PDS8 - Dual Input Fused Power Distribution Modules
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TPDK_030223
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2PDK75F16SD
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TPD2 Altronix/PDK backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (2) ACMS8CB - Dual Input PTC Access Power Controllers
- (1) VR6 - Voltage Regulator
- (1) PD8ULCB - PTC Power Distribution Module
T2PDK77F24SD
24 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TPD2 Altronix/PDK backplane
- (2) eFlow104NB - Power Supply/Chargers
- (2) ACMS12CB - Dual Input PTC Access Power Controllers
- (2) VR6 - Voltage Regulators
- (2) PDS8CB - Dual Input PTC Power Distribution Modules
