Access & Power Integration
Altronix/AMAG Kits
Models Include:
T2AMK7F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AMK7F8S
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T3AMK77F16S
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove3 enclosure with TAM3 Altronix/AMAG backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- Two (2) ACMS8 - Dual Input Fused Access Power Controllers
- Two (2) VR6 - Voltage Regulators
- Two (2) PDS8 - Dual Input Fused Power Distribution Modules
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TAMK_090623
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2AMK7F8D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AMK7F8SD
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T3AMK77F16SD
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TAM3 Altronix/AMAG backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- Two (2) ACMS8CB - Dual Input PTC Access Power Controllers
- Two (2) VR6 - Voltage Regulators
- Two (2) PDS8CB - Dual Input PTC Power Distribution Modules
More than just power.™

Advertisement

loading
Need help?

Need help?

Do you have a question about the TROVE T2AMK7F8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altronix TROVE T2AMK7F8

Summary of Contents for Altronix TROVE T2AMK7F8

  • Page 1 8 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove2 enclosure with TAM2 Altronix/AMAG backplane - Trove2 enclosure with TAM2 Altronix/AMAG backplane - One (1) eFlow104NB - Power Supply/Charger - One (1) eFlow104NB - Power Supply/Charger...

  • Page 2: Configuration Chart

    Overview: Altronix AMAG Trove kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix power supply/ chargers and sub-assemblies. Kits accommodate various combinations of AMAG modules for up to eight (8) (T2AMK1(D)) or sixteen (16) (T3AMK1(D)) doors in a single enclosure.
  • Page 3 OUT5 OUT6 OUT7 OUT8 COM (--- ) COM (--- ) PWR2 + PWR2 + Common Power Outputs (NEG) Altronix VR6 is mounted under PDS8 READER 1 Altronix ACM8 AMAG - M2150 2DBC Fig. 2a Spacer AMAG Module Backplane Pan Head...
  • Page 4 OUT5 OUT6 OUT7 OUT8 COM (--- ) COM (--- ) PWR2 + PWR2 + Common Power Outputs (NEG) Altronix VR6 is mounted under PDS8 READER 1 Altronix ACM8 AMAG - M2150 4DBC, M2150 8DBC COM C RS232 Fig. 3a Spacer...
  • Page 5 Note: AMAG M2150 2DC modules have specific markings. Please orient modules in the appropriate position according to the Fig. 4 below. 4. Fasten backplane to Trove2 enclosure utilizing lock nuts (provided). Fig. 4 - T2AMK7F8S(D) Configurations Altronix eFlow104NB AMAG - M2150 2DC PWR1 +...
  • Page 6 Note: AMAG M2150 4DBC and M2150 8DBC modules have specific markings. Please orient modules in the appropriate position according to the Fig. 5 below. 4. Fasten backplane to Trove2 enclosure utilizing lock nuts (provided). Fig. 5 - T2AMK7F8S(D) Configurations Altronix eFlow104NB AMAG - M2150 4DC PWR1 + PWR1 +...
  • Page 7 Note: AMAG M2150 modules have specific markings. Please orient modules in the appropriate position according to the Fig. 6 below. 4. Fasten backplane to Trove3 enclosure utilizing lock nuts (provided). Fig. 6 - T3AMK77F16S(D) Configurations Altronix eFlow104NB AMAG M2150-AC24/4, AMAG M2150-4DBC,...
  • Page 8 Note: AMAG M4000 modules have one (1) screen. Please make sure that they are mounted correctly, as shown in Fig. 7 below. 4. Fasten backplane to Trove3 enclosure utilizing lock nuts (provided). Fig. 7 - T3AMK77F16S(D) Configurations Altronix eFlow104NB AMAG - M4000 AMAG - M4000...
  • Page 9 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
  • Page 10 Notes: - 10 - Trove AMAG Kits Installation Guide...
  • Page 11 T2AMK7F8(D) and T2AMK7F8S(D) Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.15mm x 546.1mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77”...
  • Page 12 8.75” (222.3mm) 2” (50.8mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
