JT-DPM8600
Programmable laboratory power supply unit
1. SAFETY NOTE
Our product is suitable for up to 75 volts DC. Working with voltages
above 60 V DC is reserved for trained electricians due to the risk
of electric shock, which can lead to serious injury or death. Non-
electricians must use a voltage source below 60 volts DC.
2. GENERAL INFORMATION
Dear customer,
we would like to thank you for choosing our product. Below you will find
important information on commissioning and use. Should any unexpected
problems arise during use, please do not hesitate to contact us.
The DPM 8600 series comprises programmable power supply units that
are characterized by high performance, compact design and optimal
construction. They also feature TTL or RS485 communication protocols
and also support the Modbus RTU communication protocol. This enables
the development of custom protocols and provides a versatile solution for
design and test requirements.
!
Advertisement
Table of Contents
Related Manuals for Joy-it JT-DPM8600 Series
Summary of Contents for Joy-it JT-DPM8600 Series
- Page 1 JT-DPM8600 Programmable laboratory power supply unit 1. SAFETY NOTE Our product is suitable for up to 75 volts DC. Working with voltages above 60 V DC is reserved for trained electricians due to the risk of electric shock, which can lead to serious injury or death. Non- electricians must use a voltage source below 60 volts DC.
-
Page 2: Technical Specifications
A special feature of the DPM8600s is the ability to control them with a wire- less remote control. This remote control has a 2.4-inch LCD screen, displays many parameters, is easy to operate, contains a rechargeable lithium batte- ry and offers a range of up to 10 meters. Uniquely, multiple power supplies can be controlled simultaneously. - Page 3 4. MODULE Status display Segment display Positive outcome Negative Output Positive Entrance Negative Communication input interface Function Power switch buttons 5. DISPLAY 05 . 00 4-Fd shows voltage values Activates fast response 03 . 00 __1_ shows current values 5-CS I-SA_10_ Sets upper limit for voltage and current Simple communication...
-
Page 4: Status Display
6. STATUS DISPLAY overheating protection indicator If the temperature exceeds 80°C, this indicator lights up because the overheating protection is activated. Constant voltage display The CV display lights up when a constant voltage is output. Constant current display The CC indicator lights up when a constant cur- rent is being output. - Page 5 Press "SET" so that a value starts to light up blue. Press again to select the next value . The value can be set using the but- tons and be changed. Press "OK" to switch the output on and off. If the load current is below the set maximum current, the output switches to constant voltage mode and CV lights up.
- Page 6 If you press , you can load the saved values. You can select the data re- cords with . Press to confirm. Press to exit the temperature display. Press to return to the menu. To ca- librate the device, press .
- Page 7 Temperature display The temperature display reflects the appliance temperature, which is regulated by the fan speed and the overheating protection. if the temperature exceeds 40 °C, the fan starts working and increases its speed by one degree for every additional 5 °C. At 60 °C, the fan reaches its maximum speed. A temperature of 80 °C activates the overheating protection, which switches the appliance off automatically.
- Page 8 The menu item declares the response time of the device when discharging. Here, "0" means a slow response time and "1" a fast one. The menu item contains the communication protocol. Here, "0" means the simple communication protocol and "1" me- ans the Modbus communication protocol.
- Page 9 8. SOFTWARE We also provide you with software that you can download from our web- site: www.joy-it.de After completing the installation, connect the laboratory power supply unit to your PC via a TTL or RS485 adapter. Please note that an incorrect...
- Page 10 RS485 not connected not connected RX (weiß) TX (green) GND (black) not connected Once the cables have been connected to the power supply unit in accordance with the inst- ructions in the image and table, connect the device to the PC via USB. in the Device Manager under "Ports (COM &...
- Page 11 Attention! You must open the "DPM8608en" program for the DPM8605, but the "DPM8624en" program for the DPM8624. In the program, select the port of the power supply unit and click on "Connect" to connect the PC to the power supply unit. The baud rate is set to 9600 by default and can be set to the value set in the device if necessary.
-
Page 12: Other Information
SIMAC Electronics GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn RETURN OPTION IN YOUR AREA: We will send you a parcel stamp with which you can return the device to us free of charge. To do so, please contact us by e-mail at Service@joy-it.net or by telephone. PACKAGING INFORMATION: Please pack your old appliance securely for transportation. - Page 13 We are also there for you after your purchase. If any questions remain unanswered or problems arise, we are also available to assist you by e-mail, telephone and ticket support system. E-Mail: service@joy-it.net Ticket-System: http://support.joy-it.net Phone: +49 (0)2845 9360 - 50 (Mon. - Thur..: 09:00 - 17:00 ó clock, Fri.: 09:00 - 14:30 ó...
