JT-DPM8600
Programmable lab power supplies
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you how
to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The DPM8600 series are programmable power supplies which have a large
output power, are compact and are well structured. At the same time, it is
equipped with TTL serial communication interface or RS485 communication
interface, which provides a serial communication protocol.
It can also be applied to modbus-RTU communication protocol and supports
further development from users. Moreover, it can provide multi-purpose
solution according to your design and testing requirements.
Also, DPM8600 series can be equipped with a wireless remote control. The
wireless controller adopts 2.4-inch LCD screen. It has many display values,
a simple operation, a built-in lithium battery which can be recharged and it
can control the power supply from up to 10 meters wirelessly. The wireless
controller can control multiple power supplies simultaneously.

Advertisement

loading
Need help?

Need help?

Do you have a question about the JT-DPM8600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Joy-it JT-DPM8600

  • Page 1 JT-DPM8600 Programmable lab power supplies 1. GENERAL INFORMATION Dear customer, thank you for choosing our product. In the following, we will show you how to use your product. Should you encounter any unexpected problems during use, please do not hesitate to contact us.
  • Page 2: Technical Parameters

    This modular power supply can be applied in several aspects. It can be used for example as an ammeter, a smartmeter, a LED driver, a volatge regulator for solar panels or in an industrial control. If the device is damaged or the scope of delievery incomplete, do not use it and contact our support.
  • Page 3 3. MODULE Working status indicator LED digital tube Positive output Negative output Positive input Communication interface Negative input Function Power Switch buttons 4. DISPLAY shows voltage values Activates quick response 05 . 00 4-Fd shows current values __1_ 03 . 00 Sets upper limit of voltage and current Simple communication 5-CS...
  • Page 4 5. INDICATOR Overheat protection indicator If the temperature is greater than 80 °C, the light is activated to indicate the overheat protection. Constant voltage indicator The CV indicator light indicates constant voltage output. Constant current indicator The CC indicator light indicates constant current output.
  • Page 5 Press “SET“ that this value lights up. If you press this button again the selected digit will move one further. The value can be changed with the buttons Press “OK“ to turn on and off the output. If the load current is below the set current, the output is a cons- tant voltage.
  • Page 6 If you press , you can adjust the loaded memory. The different locations can be selected with . With you confirm your settings. Press to exit the temperature display. Press to return to the menu. To calibrate the device press .
  • Page 7 Temperature display The temperature display shows the temperature of the device which is con- trolled by the fan speed and overheat protection. If the temperature is higher than 40°C then the fan starts working. With each 5 °C the fan speed increases by one level.
  • Page 8 This menu point declares the response time of the interface when it is decharging. In that case “0“ means slow and “1“ fast. This menu point declares the communication protrocol. Here the “0“ is for the simple communication protocol and “1“...
  • Page 9: Declaration Of Conformity

    Communication protocol There are two options for the communication protocol the simple and the Modbus communication. These can be selected in the SET menu. The simple communication protocol is our custom communication protocol which is easy to undestand. The Modbus communication protocol is the standard Modbus communication protocol.
  • Page 10 If any questions remain open or problems arise after your purchase, we are available by e-mail, telephone and with a ticket support system to answer these. E-Mail: service@joy-it.net Ticket-System: http://support.joy-it.net Telephone: +49 (0)2845 98469 – 66 (10 - 17 o‘clock) For further information visit our website: www.joy-it.net...
