LABORATORY POWER SUPPLY
JT-RD6006

1. GENERAL INFORMATION

Dear customer,
thank you very much for choosing our product.
In the following, we will introduce you to what to observe while starting
up and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
The RD6006 is a constant voltage and constant current DC power supply
which can convert voltages down.
It is very easy to handle and the adjustment can either be made by key-
pad or by the encoder or even both.
It is easy and quick to store and recall data and the RD6006 is very con-
nectable with a PC or via WIFI with a handheld device in addition to that
you can use an App for control. On the 2.4 " colour screen you can read
out many values and additional information.
