LABORATORY POWER SUPPLY
JT-RD6012-C
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product.
In the following, we will introduce you to what to observe while starting
up and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
The RD6012-C is a laboratory power supply that can be used in various
operating modes (e.g. constant current or constant voltage operation,
etc.). A keypad and a push and turn encoder make the operation of the
power supply very comfortable. Furthermore, the keypad allows you to
conveniently save and reload up to nine settings. The high-resolution 2.4-
inch color display clearly shows all the important information. The USB
interface and an optional Wifi interface allow you to operate the device
via PC or with an app from mobile devices.
www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JT-RD6012-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Joy-it JT-RD6012-C

  • Page 1 LABORATORY POWER SUPPLY JT-RD6012-C 1. GENERAL INFORMATION Dear customer, thank you very much for choosing our product. In the following, we will introduce you to what to observe while starting up and using this product. Should you encounter any unexpected problems during use, please do not hesitate to contact us.
  • Page 2: Technical Specifications

    Output voltage preset value Current output current Output current preset value Overvoltage protection value Current output power Overcurrent protection value Current data group Battery-related information Constant voltage/Constant current status Battery charging indication Protection status indication www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 3: Device Overview

    Micro USB Interface Current /Overcurrent protection value setting Voltage/ Overvoltage protection value setting 4.2. Back Panel Power Source input interface External temperature sensor interface Input fuse CR1220 battery socket Fan interface Output fuse Communication module interface www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 4 4.3. Case Back Panel Main on / off switch Temperature sensor socket Ventilation openings Mains socket (do not cover) (230 V AC @ 50 Hz) www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 5: Menu Introduction

    The overcurrent protection switches off the output of the unit as soon as the current set at OCP is exceeded at the output. The overvoltage protection switches off the out- put of the device as soon as the voltage at the output exceeds the voltage set on OVP. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 6 Measure is the refresh rate of read back voltage and current on the main page, you can set it to low, middle and high. Press rotary encoder to return and it will be auto- matically saved. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 7 You can press 'SHIFT' + '0' to enter the system setting menu, then press the right but- ton three times to enter the system information menu as shown above. You can view the SN number, firmware version and system temperature here. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 8: Additional Information

    Simac GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germany Possibility of return in your area: We will send you a parcel stamp with which you can return the device to us free of charge. Please contact us by e-mail at Service@joy-it.net or by telephone. Information on packaging: If you do not have suitable packaging material or do not wish to use your own, please contact us and we will send you suitable packaging.
