Summary of Contents for Sinclair SCC-16
- Page 1 INSTALLATION MANUAL SCC-16...
- Page 2 Original instructions...
-
Page 3: Table Of Contents
3) Connection of indoor units ........................4 a) Option A............................. 4 b) Option B ............................4 4) Connection of SCC-16 to the network ....................5 5) Connection of SCC-16 to electricity ....................... 5 ADRESSING AND ACTIVATION: ........................6 1) Units addressing ............................ 6 a) Option A............................. -
Page 4: Connection
First you need to order 2-pin connection wires (length 1 m, part code 40113325) from our service department (servis@nepa.cz). You will need same number of cables as you have indoor units + one for central controller SCC-16. In example if you have 8 indoor units you will need 9 cables. -
Page 6: Connection Of Indoor Units
(NEW UNI DC INVERTER series - wired controller XK60 (30294000007)) - connection directly to the indoor unit mainboard connector COM-BMS2 or COM-BMS3 Central controller SCC-16 have to be activated via wired controller. Activation on wired controller: When unit is off press at the same time buttons Function and Timer for 5 seconds to enter configuration menu. -
Page 7: Connection Of Scc-16 To The Network
- connection to wired controller connector 4) Connection of SCC-16 to the network -connect connection cable to the CN2 (COM4) on SCC-16 mainboard 5) Connection of SCC-16 to electricity Connect L and N wires to the terminal on the mainboard of the SCC-16... -
Page 8: Adressing And Activation
ADRESSING AND ACTIVATION: 1) Units addressing a) Option A NEW UNI DC INVERTER series - wired controller (XK60, 30294000007) Multi combi series - wired controller (XK19, 30296317), Uni DC Inverter series - wired controller (30294219 ) Fan coils - wired controller (XK26, 30294223) When unit is off press at the same time Function and Mode buttons for 5 seconds to enter addressing mode. - Page 9 Switches Switches Combination Address Combination Address position position 0000 1000 0001 1001 0010 1010 0011 1011 0100 1100 0101 1101 0110 1110 0111 1111...
-
Page 10: Addresses Loading To Scc-16
SCC-16. Showing communication port and unit address: When are addresses load to the SCC-16 you can see them. Press at the same time buttons Mode and Thu for 5 seconds. On the bottom part are showed all units connected to the controller. - Page 11 Please ask your local council where your nearest disposal station is located. PRODUCER SINCLAIR CORPORATION Ltd. 1-4 Argyll St. LONDON W1F 7LD United Kingdom www.sinclair-world.com...
