Specifications
Model
VLED70B7G
Pick-up Device
1/3" Sony Super HAD CCD
Effective Pixels (H×V)
NTSC:510×492, PAL:500×582
Sensing Area
4.9mm×3.7mm
Horizontal Resolution
480 TV Lines
Minimum Illumination
0.1 Lux, 0 Lux at IR on
S/N Ratio
More than 48dB
Scanning System
2:1 Interlace
Synchronous System
Internal
Electronic Shutter
1/50s(1/60s) ～ 1 /100,000s
IR Distance
IR Leds
24 pcs Φ5 infrared LED
IR status
IR on: under 10Lux, by CDS auto control
Water Resistance
IP66
Gama Characteristic
Auto Gain Control
Auto
White Balance
Auto
Video Output
1.0Vp-p composite video, 75
Lens
3.6mm
Power/Current
12VDC/ IR on: 300mA, IR off: 100mA
Operating Temperature
14F ～ 1 22F
Storage Temperature
-4F ～ 1 40F
65'
0.45
VLED70B7G Series Color
Camera
IR Bullet Camera
IR Bullet Camera
IR Bullet Camera
IR Bullet Camera
Note : : : :
B efore applying power to the
camera, please read this UserGuide in
detail.
Advertisement
Related Manuals for Speco VLED70B7G Series
Summary of Contents for Speco VLED70B7G Series
- Page 1 Specifications VLED70B7G Series Color Model VLED70B7G Camera Pick-up Device 1/3" Sony Super HAD CCD Effective Pixels (H×V) NTSC:510×492, PAL:500×582 Sensing Area 4.9mm×3.7mm Horizontal Resolution 480 TV Lines IR Bullet Camera IR Bullet Camera IR Bullet Camera IR Bullet Camera Minimum Illumination 0.1 Lux, 0 Lux at IR on...
- Page 2 INTRODUCTION PRODUCT FEATURES CONNECTING Congratulations on your purchase of this Speco * * * * Sensor ( ( ( ( C CD ) ) ) ) product. This camera utilized the latest in SONY SONY 1/3 High Resolution CCD sensor.
