- Page 1 VLB5 /VLB6/ VLD5 VLD6M User Manual Thank you for purchasing our product. Speco Technologies is constantly developing and improving products. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
- Page 2 ■ If the product does not work properly, please contact the dealer or where the product was purchased. Speco Technologies is not responsible for any problems caused by improper operation or repair. ■ Keep away from liquid while in use.
- Page 3 You’d better install back the lens cover or lower dome less than 4 hours after removing it. The mounting types of cameras are only for reference. ►Mounting for VLB5/VLB6 1. Drill the screw holes and the cable hole on the wall according to the drill template.
- Page 4 3. Secure the mounting base with camera to the wall with screws as shown below. Rubber plug VLB6 VLB5 4. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the fixed ring to adjust the view angle of the camera. Tighten the fixed ring after the adjustment.
- Page 5 90.2mm 74.3 (mm) ∅4.6 90.2mm 74.3 VLD5 VLD6M 2. Rotate the trim ring anticlockwise to remove it from the camera. Trim ring 3. Loosen the screws to open the lower dome. Then route and connect the cables. 4. Secure the camera to the wall with screws provided as shown below. Rubber plug * Install it when routing the cables through the ceiling.
- Page 6 5. Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Pan 0°~355° Pan 0°~345° Tilt 0°~77° Turn Tilt 0°~67° Rotation 0°~345° Rotation 0°~355°...
- Page 7 Specifications Models VLB5 VLB6 VLD5 VLD6M Specifications Camera Image Sensor 1/2.8" CMOS 1/2.9" CM S Resolution Image size 1920×1080 Video Output AHD/TVI/CVI/CVBS (*camera comes defaulted to HD-TVI) Image System PAL/NTSC Electronic Shutter Auto; 1/50s~1/100000s(PAL);1/60s~1/100000s (NTSC) IR Distance (feet) 65.6~98.4 98.4 ~164.0...
- Page 8 Model: VLB5 /VLB6/VLD5/VLD6M Federal Communications Commission (FCC) Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
