VLED-EL90L Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount in hazardous locations, or near gas or electrical heaters.
• Do not let power cords touch hot surface.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
10070345 REV 2 - 04/24
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXITRONIX VLED-EL90L Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BARRON EXITRONIX VLED-EL90L Series

  • Page 1 VLED-EL90L Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
  • Page 2 VLED-EL90L Series Installation Instructions Wall Mount Installation (Fig. 2) Fig. 1 1. Insert a flat blade screwdriver into the two slots to remove front cover from backplate. (Fig 1). Remove the knockout hole on the center of the backplate. Then remove the knockouts on the backplate that correspond to the junction box holes to be used.
  • Page 3 VLED-EL90L Series Installation Instructions 7. Fasten crossbar on junction box by screws provided, fasten canopy Fig. 5 to crossbar and against the ceiling. 8. Snap chevrons to EXIT panel as needed. 9. Attach battery connector to circuit board, re-secure faceplate to unit. (Fig.
  • Page 4 VLED-EL90L Series Installation Instructions Testing and Reporting Instructions (G2 and G3/G3PRO models) 1. When AC power is supplied to fixture, the unit will automatically initiate a self-test and self-diagnostic test as follows: • Verifies battery disconnection, charger board failure at every 5 seconds. •...
