ARTERY AT32A403A Series Reference Manual

Arm-based 32-bit cortex-m4f mcu+fpu with 256 to 1024 kb flash, slib, usb, 2 cans, 17 timers, 3 adcs, 20 communication interfaces

page of 455

/ 455
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

ARM

-based 32-bit Cortex

USB, 2 CANs, 17 timers, 3 ADCs, 20 communication interfaces

Feature



Core: ARM

32-bit Cortex

− 200 MHz maximum frequency, with a Memory

Protection Unit (MPU), single-cycle multiplication

and hardware division

− Floating Point Unit (FPU)

− DSP instructions



Memories

− 256 to 1024 KBytes of Flash memory

− sLib: configure any part of main Flash as a library

area that is code executable but secured and non-

readable

− SPIM interface: extra interfacing up to 16 Mbytes of

external SPI Flash (as instruction/data memory)

− Up to 96 + 128 KBytes of SRAM

− External memory controller (XMC) with 2 Chip

Select, supporting multiplexed SRAM/NOR/PSRAM

and NAND memories

− LCD parallel interface, 8080/6800 modes



Clock, Reset, and Power management

− 2.6 V ~ 3.6 V application supply and I/Os

− Power on reset (POR)/ low voltage reset (LVR), and

power voltage monitor (PVM)

− 4 to 25 MHz crystal (HEXT)

− Internal 48 MHz factory-trimmed RC (accuracy 1%

at T

=25 °C, 2.5 % at T

automatic clock calibration (ACC)

− Internal 40 kHz RC oscillator (LICK)

− 32.768 kHz crystal oscillator (LEXT)



Low power consumption

− Sleep, Deepsleep, and Standby modes

− V

supply for RTC and 42 x 16-bit battery powered

BAT

registers (BPR)



3 x 12-bit 0.5 μs A/D converters, up to 16 channels

− Conversion range: 0 V to 3.6 V

− Triple sample and hold capability

− Temperature sensor



2 x 12-bit D/A converters



DMA: 14-channel DMA controller

− Peripherals supported: timers, ADCs, SDIOs,

Ss, SPIs, I

Cs, and USARTs



Debug Mode

−

Serial wire debug (SWD) and JTAG interface

2022.11.11

AT32A403A Series Reference Manual

-M4F MCU+FPU with 256 to 1024 KB Flash, sLib,

-M4F CPU with FPU

=-40 to +105 °C), with

− Cortex

-M4F Embedded Trace Macrocell (ETM



Up to 80 Fast I/O Interfaces

− 37/51/80 multifunctional and bidirectional I/Os, all

mappable to 16 external interrupt vectors and almost 5

V-tolerant

− All fast I/Os, control registers accessible with f



Up to 17 Timers

− Up to 8 x 16-bit general-purpose timers + 2 x 32-bit

general-purpose timers; each with 4 IC/OC/PWM or

pulse counter and quadrature (incremental) encoder

input.

− Up to 2 x 16-bit motor control PWM advanced timers

with dead-time generator and emergency brake

− 2 x Watchdog timers

− SysTick timer: 24-bit downcounter

− 2 x 16-bit basic timers to drive the DAC



Up to 20 Communication Interfaces

− Up to 3 x I

C interfaces (SMBus/PMBus)

− Up to 8 x USARTs (ISO7816 interface, LIN, IrDA

capability, and modem control)

− Up to 4 x SPIs (50 Mbit/s), all with I

multiplexed, I

S2/ I

− Up to 2 x CAN interfaces (2.0B Active)

− USB2.0 full-speed interface supporting Crystal-less

− Up to 2 x SDIO interfaces



CRC Calculation Unit



96-bit unique ID (UID)



Packages

− LQFP100 14x14 mm

− LQFP64 10x10 mm

− LQFP48 7x7 mm

− QFN48 6 x 6 mm



List of Models

Internal Flash

AT32A403ACGU7, AT32A403ACGT7,

1024 KBytes

AT32A403ARGT7, AT32A403AVGT7

AT32A403ACEU7, AT32A403ACET7,

512 KBytes

AT32A403ARET7, AT32A403AVET7

AT32A403ACCU7, AT32A403ACCT7,

256 KBytes

AT32A403ARCT7, AT32A403AVCT7

AT32A403A series: AEC-Q100 Grade 2 certified

Page 1
