RouterNode 2 (Manual)
CAUTION
Additional fixation for ceiling mounting
The device may fall from the ceiling.
Tighten the screws after sliding on the base plate.

7. Place the cover on the base plate again.
9 Installation completed.
Wiring to device
You can install the cables both on (surface-mounted) and under (flush-
mounted) plaster.
If you install the cables under the plaster, then use the opening

integrated in the base plate.
If you lay the cables on the plaster, then you must modify the housing.

ü Power supply disconnected.
1. Push the ribbed area laterally inwards and remove the housing cover.
2. Check the required width of the housing opening. The height of the
opening is approx. 7 mm. Each removed bar widens the opening by 4
mm.
3. Select a location where you want to remove the bars.
IMPORTANT
Insufficient fit due to removed clips
The housing cover is positioned and held by clips on the webs. If you saw
off or break off these clips, the housing cover will no longer be held at this
point.
1. Do not remove any bars that have a clip over them.
2. Do not damage clips during sawing.
4. Use a suitable saw to saw through the bars at both ends of the desired
opening to the base plate.
7. Installation
