- Page 1 RouterNode 2 Manual 05.03.2024...
-
Page 2: Table Of Contents
Accessories................................. 8 Connections.............................. 9 IO connector .............................. 10 Installation .............................. 12 Antenna................................ 15 Initial operation ............................ 17 IPsettings ................................ 17 RouterNode 2 in the WaveNet Manager..................... 18 Browser interface ............................. 19 10. Maintenance.............................. 23 Signalling.............................. 24 Fault rectification ............................ 25 12.1 Reset.................................. 25 Technical specifications........................ 27 13.1... -
Page 3: General
NOTE Compatibility with System 3060 The device is also used with other firmware in other product families. You can only use the device with this firmware (=RouterNode 2) in System 3060. Check the article number. ... -
Page 4: General Safety Instructions
2. General safety instructions RouterNode 2 (Manual) 4 / 34 2. General safety instructions Signal word: Possible immediate effects of non-compliance WARNING: Death or serious injury (possible, but unlikely) CAUTION: Minor injury IMPORTANT: Property damage or malfunction NOTE: Low or none... - Page 5 2. General safety instructions RouterNode 2 (Manual) 5 / 34 Damage as a result of overcurrent or overvoltage This product contains electronic components that may be damaged by excessive current or voltage. Do not exceed the maximum permissible voltages and/or currents.
-
Page 6: Product-Specific Safety Instructions
3. Product-specific safety instructions RouterNode 2 (Manual) 6 / 34 3. Product-specific safety instructions CAUTION Risk of burns due to hot circuit board If you power the device with Power-over-Ethernet (PoE), the board can be- come very hot. Allow the unit to cool down before opening the housing. -
Page 7: Meaning Of The Text Formatting
4. Meaning of the text formatting RouterNode 2 (Manual) 7 / 34 4. Meaning of the text formatting This documentation uses text formatting and design elements to facilitate understanding. The table explains the meaning of possible text formatting: Example button... -
Page 8: Scope Of Delivery
5. Scope of delivery RouterNode 2 (Manual) 8 / 34 5. Scope of delivery RouterNode 2: Cover, base plate with circuit board and three pre- assembled strain reliefs Removable sticker with Chip-ID Quick guide 5.1 Accessories You can use optionally available accessories to adapt your device to different applications. -
Page 9: Connections
O 1.NC O 1.NO O 1.COM DC In RJ45 NOTE IO connector only for RouterNode 2 You can only use the connectors of the IO connector at RouterNode 2. Connection Meaning Power supply with round DC In Pin connector plug connector... -
Page 10: Io Connector
6. Connections RouterNode 2 (Manual) 10 / 34 Connection Meaning Open drain output (for details, see connector [ 10] Technical spe- cifications [ 27] Open drain output (for details, see connector [ 10] Technical spe- cifications [ 27] Potential-free relay output: Normally Closed (NC). - Page 11 11 / 34 Evaluation of an analogue signal The RouterNode 2 digitises the voltage level and compares the values with a threshold value. You can configure this threshold value in the WaveNet Manager and trigger an analogue event. In LSM event management, you specify how the system is to respond to the occurrence of this event.
-
Page 12: Installation
7. Installation RouterNode 2 (Manual) 12 / 34 7. Installation The device can be fitted horizontally or vertically. You can fit it in a horizontal position easily and safely using the integrated mounting holes. Take into account the internal antenna’s directional characteristic (see Antenna [ 15]... - Page 13 7. Installation RouterNode 2 (Manual) 13 / 34 2. Hold the base plate in the required position and mark the drill holes. Version 1: Left-hand opening Version 2: Right-hand opening Base 3. Drill the required holes with a suitable drill.
- Page 14 7. Installation RouterNode 2 (Manual) 14 / 34 CAUTION Additional fixation for ceiling mounting The device may fall from the ceiling. Tighten the screws after sliding on the base plate. 7. Place the cover on the base plate again.
-
Page 15: Antenna
7. Installation RouterNode 2 (Manual) 15 / 34 5. Bend the bars back and forth at the desired opening until the bars break. The housing is designed to be mounted on a surface. 7.1 Antenna The internal antenna radiates as shown. The transmitting and receiving... - Page 16 7. Installation RouterNode 2 (Manual) 16 / 34 Dowels and screws You do not need to change any settings after connecting the external antenna. When the external antenna is connected, the device transmits via the internal and external antennas (the internal antenna is not disabled by connecting the external antenna).
-
Page 17: Initial Operation
3. Connect the device to your network. 4. Use the OAM-Tool to determine the IP address of your device in the network (see OAM-Tool manual). RouterNode 2 in the WaveNet 5. Connect the device to your system (see Manager [ 18]... -
Page 18: Routernode 2 In The Wavenet Manager
The window "Network options" opens. 10. Click on the Yes button. RouterNode 2 is imported in the WaveNet topology. You can then expand your WaveNet with WaveNet-enabled locks and import the WaveNet topology. For more information, refer to the WaveNet... -
Page 19: Browser Interface
9. Browser interface RouterNode 2 (Manual) 19 / 34 9. Browser interface You can use the Ethernet interface in the browser to configure the following for RouterNodes, GatewayNodes and SmartBridges: Allow changes using the OAM tool Password for the web interface ... - Page 20 9. Browser interface RouterNode 2 (Manual) 20 / 34 4. Click on the OK button. The browser interface system overview is visible. NOTE Web interface can no longer be used with the default password with firmware 40.12 and above The browser interface remains blocked in firmware version 40.12 or above until the default password has been changed.
- Page 21 Browser interface opened. 1. Open the [PORT] tab using | CONFIGURATION |. You will see an overview of the TCP port settings for RouterNode 2. 2. Select the option "Yes" (enable the OAM tool to change the IP) or the option "No" (block change to the IP by the OAM tool) from the ▼ OAM- Tool allow drop-down menu.
- Page 22 Browser interface opened. 1. Open the [PORT] tab using | CONFIGURATION |. You will see an overview of the TCP port settings for RouterNode 2. 2. Select the "Yes" option (open SMTP port) or the "No" option (close SMTP port) from the ▼ SMTP Port drop-down menu.
-
Page 23: Maintenance
10. Maintenance RouterNode 2 (Manual) 23 / 34 10. Maintenance The device itself is maintenance-free. However, the performance of radio networks will always depend on environmental influences. These influences can change and affect the performance of your radio network. You should therefore check the network configuration and performance of your radio network at regular intervals. -
Page 24: Signalling
11. Signalling RouterNode 2 (Manual) 24 / 34 11. Signalling Signal Meaning Green flashing (~1.5 Hz) Configured and ready to use. Not configured, but ready for opera- Green flashing (~0.3 Hz) tion Red flashing (briefly) Restart Green flickering Data transfer... -
Page 25: Fault Rectification
12. Fault rectification RouterNode 2 (Manual) 25 / 34 12. Fault rectification If problems occur during operation, you may be able to rectify them yourself: 1. Check the power supply of the affected devices. 2. Check the network connection. 3. Check the authorisations assigned. - Page 26 12. Fault rectification RouterNode 2 (Manual) 26 / 34 Reset network configuration 1. Disconnect the power supply (round plug or network cable for PoE). 2. Wait 20 seconds. 3. Press and hold the reset button. 4. Reconnect the power supply (round plug or network cable for PoE).
-
Page 27: Technical Specifications
Spring terminal block 10-pin, wire Connections (can only be used on diameter 0.14 (rigid) or 0.2 (flexible) RouterNode 2) to 0.5 mm (IO connector, can only be used with RouterNode 2) Environment Operational: -10 °C to +55 °C Temperature Storage: -20 °C to +60 °C ... - Page 28 13. Technical specifications RouterNode 2 (Manual) 28 / 34 to 32 V (reverse polarity protec- ted) or PoE according to IEEE 802.3af Power supply via PoE and round plug Operating voltage possible simultaneously: round plug > 12 V → Round plug used, round plug <...
-
Page 29: Optional External Antenna
13. Technical specifications RouterNode 2 (Manual) 29 / 34 RGB LED (centre of housing) Software Programming via TCP/IP interface Radio emissions 868.000 MHz - 868.600 MHz / 869.700 MHz <25 mW ERP - 870.000 MHz 13.1 Optional external antenna 13.1.1 Electrical specifications... -
Page 30: Connection Specifications
13. Technical specifications RouterNode 2 (Manual) 30 / 34 Impedance 50 Ω Polarization Linear Gain 2,2 d Bi max. VSWR < 3:1 Operating temperature -40 ° C to +85 ° C 13.1.2 Connection specifications Connector type MCX male Cable RG174U Cable length 250 ... -
Page 31: Declaration Of Conformity
14. Declaration of conformity RouterNode 2 (Manual) 31 / 34 14. Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that the articles (WNM.RN2.*, WN.RN2.*) comply with the following guidelines: 2014/53/EU -RED- or for the UK: UK statutory 2017 No. 1206 -Radio equipment- 2011/65/EU -RoHS- ... -
Page 32: Help And Other Information
15. Help and other information RouterNode 2 (Manual) 32 / 34 15. Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: https://www.simons-voss.com/en/documents.html Software and drivers Software and drivers can be found on the website: https://www.simons-voss.com/en/service/software-downloads.html... - Page 33 15. Help and other information RouterNode 2 (Manual) 33 / 34 Address SimonsVoss Technologies GmbH Feringastr. 4 D-85774 Unterfoehring Germany...
- Page 34 This is SimonsVoss SimonsVoss, the pioneer in remote-controlled, cable-free locking technology provides system solutions with a wide range of products for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems combine intelligent functionality, high quality and award- winning design Made in Germany. As an innovative system provider, SimonsVoss focuses on scalable systems, high security, reliable components, powerful software and simple operation.
