Preparation
4. Preparation
4.1. Cabling
Have the following cables available:
• Power cable.
• Ethernet cable for configuration.
• Ethernet cable x 1 for connecting to the network.
• 7-pin screw terminal block connector is included with the product.
4.2. Mechanical Tools and Equipment
Have the following tools available:
• Flat-head screwdriver, size 5.5 mm
Needed when removing the Communicator from DIN-rail.
• Flat-head screwdriver, size 3 mm
Needed when connecting the cables to the 7-pin connector.
4.3. HMS Software Applications
Download the software installation files and user documentation from
www.anybus.com/support.
HMS IPconfig
Use the software application HMS IPconfig and scan your network to discover and change
the Communicator IP address and to access the Communicator built-in web interface.
NOTE
As an alternative, you can set a static IP address within the same IP
address range as the Communicator IP address on the computer accessing
the Communicator built-in web interface.
NOTE
HMS IPconfig is only available for Windows.
