Connector Port Guide
5.2. Connector Port Guide
Figure 2. Communicator connector ports
Position
Port Number
A
X1
B
X3
C
X2.1
D
X2.2
SP2954 Version 1.12
Anybus
Connector
Port Usage
Ethernet
Configuration port
Serial
Serial RS-232/485 Device
Ethernet
PROFINET network
Ethernet
PROFINET network
®
™
Communicator
- PROFINET to Modbus
RTU/Serial
Page 9 of 28
