Anybus
Communicator
RTU/Serial
5.8. DIN Rail Demount
Before You Begin
IMPORTANT
Be careful when removing the Communicator from the DIN-rail. If not
removed properly, the DIN rail locking mechanism and the product cover
can break.
Have a flat-blade screwdriver, size 5.5 mm, available.
Procedure
Remove the Communicator from the DIN rail:
1.
Insert the screwdriver into the Communicator DIN rail locking mechanism.
2.
To unlock the Communicator DIN rail locking mechanism, turn the screwdriver
clockwise.
Figure 9. Unlock the Communicator
Page 18 of 28
™
- PROFINET to Modbus
DIN Rail Demount
SP2954 Version 1.12
