Communicator LED Indicators
8. Communicator LED Indicators
NOTE
Before you can verify operation, you must configure the Communicator.
Figure 13. Communicator status (A), High level Network/Client (B), Subnetwork 2 (C) and
(D) Security Switch
LED A
Operation Gateway status
status
Off No power
Green, flashing Startup phase
SP2954 Version 1.12
Anybus
LED B LED C
PROFINET Slave Subnetwork
No connection with No power/
IO controller Subnetwork not
running/Node is
switched off via a
control word
Used by engineering Running, one or more
tools to identify the nodes are offline
node on the network
® ™
Communicator - PROFINET to Modbus
LED D
Security switch
No power/Security
switch is unlocked
N/A
RTU/Serial
