Connect to Serial RS232/RS485 Subnetwork
5.4. Connect to Serial RS232/RS485 Subnetwork
NOTE
Use minimum 90 oC copper (Cu) wire only.
Figure 4. Connect to serial RS232/RS485 subnetwork
SP2954 Version 1.12
®
Anybus
Communicator
- PROFINET to Modbus
RTU/Serial
Page 11 of 28
