Anybus Communicator
RTU/Serial
LED A
Operation Gateway status
status
Green, one Startup phase
flash
Green, solid Operational
Red, solid N/A
Red, one flash N/A
Red, two flash N/A
Red, three N/A
flash
Red, flashing Invalid configuration
Green/Red, Power up self-test/
flashing Firmware update/
Firmware recovery
Fatal Error and Exception Error
Fatal error: A fatal error causes the Communicator firmware application to crash in an
uncontrolled manner.
Exception error: An exception error causes the Communicator to enter a controlled error
state. The Communicator firmware application is still running.
LED Fatal error
A Red, solid
B Red, solid
C Red, solid
D Off
Page 26 of 28
™
- PROFINET to Modbus
LED B
PROFINET Slave
Connection with IO
controller establish IO
controller in STOP
state or IO data bad
PROFINET network
online, one or
more connections
established
FATAL event
Station name not set.
IP address not set
Expected
Identification differs
from Real
Identification
One or more
connections timed
out
N/A
Fatal Error and Exception Error
LED C LED D
Subnetwork Security switch
Running, one or more N/A
nodes are offline
Running Security switch is
locked
N/A N/A
N/A N/A
N/A N/A
N/A N/A
All nodes are offline N/A
N/A N/A
Exception error
Red, solid
Off
Off
Off
