Security Switch - HMS Networks Anybus Communicator SP2954 Startup Manual

Security Switch

5.6. Security Switch
IMPORTANT
After completing the configuration of the Communicator, lock the security
switch to prevent unauthorized access to the Communicator built-in web
interface.
When the security switch is in its locked position, the Communicator built-in web interface
cannot be accessed, and the Communicator cannot be configured using the built-in web
interface. Network specific parameters, configured via the PLC is still available.
To Lock and Unlock the Security Switch
Figure 6. Security switch in locked and unlocked position
SP2954 Version 1.12
®
Anybus Communicator
™
- PROFINET to Modbus
RTU/Serial
Page 15 of 28
