Anybus Communicator
RTU/Serial

7. Technical Data

For complete technical specifications and regulatory compliance information, please visit
www.anybus.com.

7.1. Technical Specifications

Article identification
Configuration connector
Communication connector
Serial connector
Power connector
Power supply
Power consumption
Storage temperature
Operating temperature
Humidity
Vibration
Housing material
Protection class
Product weight
Dimensions
Mounting
Page 24 of 28
™
- PROFINET to Modbus
ABC3013
RJ45
RJ45 x 2
7-pin screw connector
3-pin screw connector
12-30 VDC, Reverse voltage protection and short circuit protection
Typical: 90 mA @ 24 V (2.2 W) Max: 3 W
-40 to +85 °C
-25 to +70 °C
EN 600068-2-78: Damp heat, +40°C, 93% humidity for 4 days
EN 60068-2-30: Damp heat, +25°C – +55°C, 95% RH, 2 cycles
See datasheet
Plastic, See datasheet for details
IP20
150 g
27 x 144 x 98 mm (W x H x D) with connectors included
DIN-rail
Technical Data
SP2954 Version 1.12
