INSTALLATION INSTRUCTIONS
Square
Slide Bar
Model D35700430
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing,
supply stores. It is essential that the tools and materials be on hand before work is begun.
Drill
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Phillips Screwdriver
Hammer
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
Level
- 1 -
Flat Blade Screwdriver
10'
Tape Measure
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
M965595 Rev. 1.0 (5/17)
Advertisement
Related Manuals for DXV CONTEMPORARY D35700430
Summary of Contents for DXV CONTEMPORARY D35700430
- Page 1 INSTALLATION INSTRUCTIONS Square Slide Bar Model D35700430 Thank you for selecting DXV. To ensure that your installation proceeds smoothly, please read these instructions carefully before you begin. RECOMMENDED TOOLS AND MATERIALS Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing, supply stores.
- Page 2 ROUGHING-IN DIMENSIONS: • For reference 57 mm (2-1/4") 65 mm (2-9/16") 618 mm (24-3/8") *600 mm (23-5/8") 51 mm (2") 57 mm (2-1/4") 84.5 mm (4-3/16") 18 mm (11/16") 18 mm OPTIONAL TO FINISHED FLOOR (11/16") USUALLY BETWEEN 915 mm 1525 mm (36") (60")
- Page 3 INSTALL ADJUSTABLE SLIDE BAR • The SLIDE BAR (1) works best when secured to the wall studs or cross brace using the WOOD SCREWS. If mounting into the studs is not possible, use appropriate wall fasteners provided to secure the installation. •...
- Page 4 Square Slide Bar MODEL NUMBER D35700430 Replace the “YYY” with appropriate finish code POLISHED CHROME BRUSHED NICKEL M964521-0070A MOUNTING KIT M964711-YYY0A HAND SHOWER BRACKET M964531-0070A SET SCREW M965595 Rev. 1.0 (5/17) - 4 -...
