Terminals
The default designation is as shown below, however all 5 relays are user-configurable.
Field Terminals
Default Operation
NO, C, and NC
TROUBLE RELAY
NO, C, and NC
FIRE RELAY
NO, C, and NC
SUPERV RELAY
NO, C, and NC
PROG 1 RELAY
NO, C, and NC
PROG 2 RELAY
VES Fire Detection Systems
Compas Fire Alarm Control Panel Installation Manual
Main Back Board (S722)
Default Setting
Trouble
Fire
Supervisory
Transparent
Transparent
Version 4.00 | January 2024 | MAN-1431COM
