Buzzer activation during the Autolearn Panel function is part of configuration process. Once Autolearn is
complete, the panel will initialize loop devices with the default settings.
5. Once device initialization is complete, address any outstanding troubles that may be reported.
6. Confirm that the Fire System Normal condition is displayed following the booting cycle.
A "comms time-out" trouble occurs following the booting sequence when the Compas Fire Alarm Control Panel
includes a network card. Reset the panel in Access Level 2 of the menu to obtain the Fire System Normal
condition when this trouble condition occurs.
7. Test and verify that all inputs and outputs operate as intended and in accordance with NFPA 72 guidelines.
Testing the Panel GUI
Perform the following tests to confirm proper operation of the buzzer, panel GUI, indicator lamps, and the fire
control panel system.
The Fire System Normal screen displays when the Compas Fire Alarm Control Panel is operating properly
and indicates that the installation was successful. Determine that the Fire System Normal condition is visible on
the panel GUI before initiating the Panel Tests. Fire System Normal condition is displayed following the
booting cycle and occurs when trouble conditions are not reported.
Panel Tests
Panel Tests are provided through the No User Group of the panel GUI. No User Group contains a limited set
of operations and does not require password authorization to initiate. The No User Group menu is immediately
available for operation following the booting cycle.
Lamp & Buzzer Test
This test confirms operation of the indicator lamps and the buzzer. To perform the Lamp & Buzzer Test:
VES Fire Detection Systems
Compas Fire Alarm Control Panel Installation Manual
Version 4.00 | January 2024 | MAN-1431COM
Installation
Page 54
