SLC Loop Ratings
The following ratings represent Hochiki DCP Protocol SLC loops of the Compas Fire Alarm Control Panel.
Connection
LOOP ( - OUT ), ( + OUT )
LOOP ( - IN ), ( + IN )
The following ratings represent Apollo Protocol SLC loops of the Compas Fire Alarm Control Panel.
Connection
LOOP ( - OUT ), ( + OUT )
LOOP ( - IN ), ( + IN )
Maximum Cable Capacitance: 1 µF
Maximum Wiring Voltage Loss: 6.4 V
Refer to
SLC Loop Cabling
VES Fire Detection Systems
Compas Fire Alarm Control Panel Installation Manual
Rating
36 V DC @ 400 mA
36 V DC @ 400 mA
Rating
27 V DC @ 400 mA
27 V DC @ 400 mA
for maximum allowable cable length calculations.
Appendix A: Specifications
Version 4.00 | January 2024 | MAN-1431COM
Page 122
