Replacement Parts

The following replacement parts are provided for the Compas Fire Alarm Control Panel. All part quantities are
"one" unless otherwise indicated in parentheses.
Models Description
MAN-1431 Compas Fire Alarm Control Panel - Installation Manual
S406 5.25 Amp Power Supply, 115 VAC / 230 VAC
S408 10.25 Amp Power Supply, 115 VAC / 230 VAC
S721 LCD Main Processor Board
S722 Main Back Board Equipment List
S723 Compas Network Module
S752 Power Supply Accessory Kit
S758 Dual Loop Panel Module Equipment List
S768 Compas Printer
S769 System A Panel Module Equipment List
S770 System B Panel Module Equipment List
S771 Zone LED Module
S787 Compas Vision Unit
KB3472 Thermal Paper Rolls, 58 mm wide
SR1016
40 Conductor IDC Cable
SR1017
34 Conductor IDC Cable
SR1023
10 Conductor IDC Zone LED Cable
SR1020
14 Conductor IDC PSU Signal Cable
SR1024
10 Conductor IDC Zone LED to LED Cable
SR1018
10 Conductor IDC Printer Cable
SKW91BLACK
PSU Power 0V Cable
SKW91RED
PSU Power 24V Cable
S2028-6
Resistor Kit (6) 10K Ohm, EOL
S2028
Resistor 10K, EOL
S2063-4
Resistor Kit (4) 3.3 K Ohm, EOL
S2063
Resistor 3.3 K Ohm, EOL
S2029
EOL Diode
S007 Panel Key Lock Set
B3532 Panel Cabinet Lock
B1828 Key Switch
M117 Hinge Pins (Long)
M118 Hinge Pins (Short)
