Ducting Configurations
Front Exhaust with Remote Blower
Note: External or in-line blowers require 10" ducting.
Side Exhaust with Remote Blower
Downdraft
1-7/8" to
10" Round Transition
Note: External or in-line blowers require 10" ducting.
(continued)
Downdraft
10"
Straight Duct
10" Round Elbow
*
* To one of the following:
Model CBE-1000 External Blower
• Model PBN-1000A In-line Blower
10"
Straight Duct
10"
Round Elbow
*
* To one of the following:
Model CBE-1000 External Blower
• Model PBN-1000A In-line Blower
8
Planning
