Mounting Instructions LANCOM AirLancer ON-Q30
DEF
DEF
A
DEF
Overview of the mounting kit
1 connection flange (A)
1 connection arm (B)
1 pole flange / wall bracket
4 washers M6 (D)
(E)
4 spring washers M6
(F)
4 nuts M6
1 pole clamp for pole diameter up to 62.5 mm
2 hexagon head screws M8x35
4 spring washers M8 (K)
(L)
4 washers M8
(M)
2 nuts M8
2 hexagon head screws M8x70
Not included in the scope of delivery
2 band clamps for pole diameter > 62.5 mm (H)
Screws and dowels for wall mounting
Mounting the antenna flange and connection arm
Screw the connection flange
housing using the enclosed washers (D), spring washers (E),
and nuts (F). Make sure that the spring washers
directly under the nuts (F).
Then fasten the connection arm
(A) using a screw (J), a spring washer (K), a washer (L), and a nut (M). Make sure that
flange
(L)
the spring washer

Preparation for wall mounting

If you want to mount the antenna on a wall, use the wall mount
mark the drill holes for wall mounting.
Drill the corresponding holes at the markings and insert dowels (not included) into them if
necessary. Depending on the wall material and condition, the depth and diameter of the holes
must be adjusted.
B
(C)
(I)
(J)
(N)
(A)
to the back of the antenna
(B) hand-tight to the connection
is located directly under the screw head.
H
C
(E) are located
(C) as a drilling template to
