- Page 1 Mounting Instructions LANCOM AirLancer ON-QT60 / ON-QT90...
- Page 2 Mounting Instructions LANCOM AirLancer ON-QT60 / ON-QT90 Übersicht des Befestigungs-Kits Mounting kit contents 1 Conection flange 1 Connection arm 1 Pole flange / wall bracket 2 Hexagon head screws M5x25 6 Spring washers M5 6 Washers M5 6 Nuts M5 2 Band clamps 2,5“...
- Page 3 Mounting instructions LANCOM AirLancer ON-QT60 / ON-QT90 Wall mounting of the antenna Align the wall bracket with the drill holes and fasten it with suitable screws. Now fasten the connecting arm (B), which is already mounted on the antenna, to the connecting flange hand-tight using a screw (D), a spring washer (E), a washer (F), and a nut (G).
- Page 4 Mounting Instructions LANCOM AirLancer ON-QT60 / ON-QT90 Important information Responsible handling of high frequency In order to comply with the protection requirements of EU Directive 2014/53 and EN 62479 with regard to the basic restrictions for the safety of persons in electromagnetic fields and the „FCC Policy on Human Exposure to Radiofrequency Electromagnetic Fields“, it is necessary to...
- Page 5 Adenauerstr. 20/B2 their owners. This document contains statements relating to future products and their attributes. LANCOM Systems reserves the right 52146 Wuerselen | Germany to change these without notice. No liability for technical errors info@lancom.de...
