- Page 1 LANCOM Antenna AirLancer IN-Q180...
-
Page 2: Mounting Instructions
MOUNTING INSTRUCTIONS Preparation for wall- and ceiling mounting Use the antenna as a drilling template to mark out the drill holes for wall- or suspended ceiling mounting. The horizontal and vertical separation of the adjacent holes is 104 mm. For ceiling mounting, if required, drill a hole into the center of the ceiling board to feed-through the connector cables. - Page 3 MOUNTING INSTRUCTIONS 2. Ceiling mounting with screws and clips Included: 4 clips, 4 thread screws 15 mm Push the clips into the appropriate slides at the backside of the antenna, so that the clips are placed in line with the holes in the antenna housing. Stick the thread screws through the holes in the antenna housing from the front side and loosely connect the screws to the clips.
- Page 4 LCOS (changing the antenna grouping of the respective Wi-Fi module), and configure the antenna gain. The settings can be found in LANconfig, resp. in the detail configuration of the LANCOM Management Cloud at: Configuration > Wireless LAN > General > Physical WLAN settings > Radio...
- Page 5 Technical details 2400 - 2500 MHz (red marked connectors), Frequency range 4900 - 5900 MHz (white marked connectors) Antenna characteristics horizontal (2.4 GHz) 360° vertical (2.4 GHz) 55° Radiation characteristics horizontal (5 GHz) 220° vertical GHz) 40° Recommended use Room coverage VSWR 1.5:1 typ.
