Mounting Instructions LANCOM AirLancer ON-Q30
Technical data
Frequency range
Antenna characteristics
Radiation patterns
Recommended use
VSWR
Gain
Mechanical Data
Dimensions (mm)
Operating temperature
Color
Material
Mounting options
Cables & Connectors
Item
Warranty
Item no.
Scope of delivery
LANCOM Systems GmbH
A Rohde & Schwarz Company
Adenauerstr. 20/B2
52146 Wuerselen | Germany
info@lancom.de | lancom-systems.com
2,400-2,500 MHz, 5,150-5,875 MHz
Horizontally: 30°
Vertically: 30°
Sector coverage
2.0:1 max.
10 dBi max.
370 x 370 x 30 (W x H x D)
-40° C to 85° C
Light grey
UV resistant plastic
Wall- and pole mounting, alignable
4x 100 cm ULA100 cable with N-Plug connector
2 years for AirLancer and accessories
61266
Antenna, 4 connection cables, mounting kit for wall and pole mounting
