- Page 1 Mounting Instructions LANCOM AirLancer O-360D-5G...
-
Page 2: General Notes
Mounting Instructions LANCOM AirLancer O-360D-5G General notes The AirLancer O-360D-5G comes with materials for wall and pole mounting. The antenna must be installed so that the antenna outputs point downwards. The antenna has SMA connectors to which LANCOM indoor mobile routers can be connected. The screw connections should not be exposed to the weather. -
Page 3: Wall Mounting
Mounting instructions LANCOM AirLancer O-360D-5G 2. Wall mounting First fix the bracket to the wall with suitable screws as shown. Then attach the second bracket to the antenna with the screws and washers provided as shown. Finally fix the antenna with the screwed bracket to the bracket on the wall. -
Page 4: Safety Instructions
Mounting Instructions LANCOM AirLancer O-360D-5G Important information Electrical and Electronic Equipment Act Please do not throw electrical and electronic scrap into the household waste, it cannot be recycled there. Make sure that your electrical and electronic waste is disposed of in accordance with the currently valid guidelines of your country. - Page 5 Adenauerstr. 20/B2 their owners. This document contains statements relating to future products and their attributes. LANCOM Systems reserves the right 52146 Wuerselen | Germany to change these without notice. No liability for technical errors info@lancom.de...
