- Page 1 LANCOM Antenna AirLancer ON-Q60ag...
-
Page 2: Mounting Instructions
MOUNTING INSTRUCTIONS Preparation for wall mounting Use the antenna as a drilling template to mark out the drill holes for the wall mounting. The horizontal and vertical separation of the adjacent holes is 173.7 mm. Size of the drill holes Using the markings as a guide, drill the holes and insert dowels if appropriate. - Page 3 MOUNTING INSTRUCTIONS Important Working responsibly with high frequencies The AirLancer ON-Q60ag meets the requirements of the R&TT directives EN62479 and the FCC regulations. To ensure compliance with these requirements, a minimum distance of 20 cm must be maintained between the antenna and the human body when operating the antenna.
-
Page 4: Operating Mode
MOUNTING INSTRUCTIONS Important Antenna gain and terminating unused antenna connectors on the access point It is essential for unused antenna connectors on the access point to be terminated with the supplied rod antenna. The terminating resistor supplied with the adapter AirLancer AN-RPSMA-NJ is suitable for use with indoor access points. -
Page 5: Antenna Characteristics
Technical details Frequency range 2400 - 2500 MHz, 4900 - 5900 MHz Antenna characteristics horizontal (2.4 GHz) 65° vertical (2.4 GHz) 65° Radiation characteristics horizontal (5 GHz) 65° vertical GHz) 65° Recommended use Point-to-multipoint, sector VSWR 1.5:1 typ. / 2.0:1 max. 2.4 GHz 6.5 dbi max.
