- Page 1 LANCOM Antenna AirLancer ON-Q360ag...
-
Page 2: Mounting Instructions
MOUNTING INSTRUCTIONS Attaching the antenna bracket by wall mounting In the case of wall mounting, attach the antenna bracket to the wall with the enclosed bolts. You may need to drill the holes first and insert dowels. Attaching the antenna bracket by pole mounting In the case of pole mounting, use screw clamps to attach the antenna bracket directly to the pole. - Page 3 Important Working responsibly with high frequencies The AirLancer ON-Q360ag meets the requirements of the R&TT directives 1995/5/EC and the FCC & ARPANSA regulations. To ensure compliance with these requirements, a minimum distance of 20 cm must be maintained between the antenna and the human body when operating the antenna.
-
Page 4: Operating Mode
WLAN modules operating in two different frequency ranges. This is done by connecting two of the connectors to each WLAN module. As the AirLancer ON-Q360ag has antenna segments that are aligned equally to one another, you are free to choose your arrangement. -
Page 5: Antenna Characteristics
Technical details Frequency range 2400 - 2500 MHz, 4900 - 5900 MHz Antenna characteristics horizontal (2.4 GHz) 360° vertical (2.4 GHz) 60° Radiation characteristics horizontal (5 GHz) 360° vertical GHz) 33° Recommended use Hotspot, coverage of open spaces VSWR 2.0:1 max. 2.4 GHz 4 dbi max.
