- Page 1 Mounting Instructions LANCOM AirLancer ON-Q30...
-
Page 2: Preparation For Wall Mounting
Mounting Instructions LANCOM AirLancer ON-Q30 Overview of the mounting kit 1 connection flange 1 connection arm 1 pole flange / wall bracket 4 washers M6 4 spring washers M6 4 nuts M6 1 pole clamp for pole diameter up to 62.5 mm... - Page 3 Mounting Instructions LANCOM AirLancer ON-Q30 Wall mounting of the antenna Align the wall bracket with the drill holes and fasten it with suitable screws. Now hand-tighten the connection arm already mounted on the connection flange to the wall bracket using a screw (J), a spring washer (K), a washer (L), and a nut (M).
- Page 4 Mounting Instructions LANCOM AirLancer ON-Q30 Important information Responsible handling of high frequency In order to comply with the protection requirements of EU Directive 2014/53 and EN 62479 with regard to the basic restrictions for the safety of persons in electromagnetic fields and the „FCC Policy on Human Exposure to Radiofrequency Electromagnetic Fields“, it is necessary to...
- Page 5 Adenauerstr. 20/B2 their owners. This document contains statements relating to future products and their attributes. LANCOM Systems reserves the right 52146 Wuerselen | Germany to change these without notice. No liability for technical errors info@lancom.de...
