Wall mounting of the antenna
Align the wall bracket with the drill holes and fasten it with suitable screws.
Now hand-tighten the connection arm
connection flange (A)
spring washer (K), a washer (L), and a nut (M).
Make sure that the spring washer
screw head and that the arrow on the back of the antenna housing is
pointing upwards.
Align the antenna according to your wishes and then tighten the
screws of the connection arm with suitable torque.
Pole mounting of the antenna
Position the pole flange
bearing capacity. Use the pole clamp
Fasten the pole clamp
the two screws (N), the spring washers (K), and the
washers (L). Please note that the mast clamp must be
rotated depending on the mast diameter.
For pole diameters over 62.5 mm, you need suitable band
clamps (H) (not included in the scope of delivery) and
guide them through the pole flange and around the pole
as shown in the overview
and tighten them after you have aligned the pole
flange.
Then connect the pole flange
the antenna using an enclosed screw (J), a spring washer (K),
a washer (L), and a nut (M).
Make sure that the spring washer
arrow on the back of the antenna housing is pointing upwards.
Align the antenna according to your requirements and then tighten the screws of the
connection arm with suitable torque.
(B) already mounted on the
to the wall bracket (C)
(K)
is located directly under the
(C) at the desired height on a suitable pole with sufficient load-
(I)
to attach to poles up to 62.5 mm in diameter.
(I)
to the pole flange
(C) hand-tight to the connection arm
(K)
is located directly under the screw head and that the
using a screw (J), a
(C)
using
(B) already mounted on
