- Page 1 LANCOM Antenna AirLancer ON-D9a...
-
Page 2: Mounting Instructions
MOUNTING INSTRUCTIONS Mounting preparation Mounting bolt Fix the mounting bracket (antenna) to the corresponding Mounting bolt mounting bolts for 0° or 45° orientation at the backside of the antenna using a hex nut, a flat washer, and a lock washer per bolt as shown in the diagram. Mounting bolt Connect the mounting bracket (antenna) and the mounting DRAIN HOLES... -
Page 3: Pole Mounting
Align the antenna according to your needs and tighten all nuts firmly. Connecting to the access point Antennas of the AirLancer ON-D9a model feature two antenna connectors for the parallel transmission of two data streams in combination with a LANCOM 802.11n / 802.11ac MIMO Access Point. - Page 4 Important Working responsibly with high frequencies The AirLancer ON-D9a meets the requirements of the R&TT directives EN62479 and the FCC regula- tions. To ensure compliance with these requirements, an adequate safety distance must be main- tained between the antenna and the human body when operating the antenna.
- Page 5 Technical details Frequency range 4900 - 5900 MHz Antenna characteristics horizontal 9° Radiation characteristics vertical 9° Recommended use Point-to-Point VSWR 1.5:1 typ. / 2.0:1 max. Gain 23 dbi Mechanical details Size 340 x 340 x 30 mm (length x width x height) Weight 1.6 kg (antenna without mounting kit) Temperature range...
