DOOR PANEL REMOVAL

Use the following instruction to remove the front door panel
below the docking station.
When replacing the door, reverse the order making sure the
Logo is properly connected first.
2
Go to the 3 locking
clip and use the
following steps to
remove each one.
3
Grab panel on bottom edge pull out and and lower
4
Disconnect logo light
wire from back side of
door panel
II)
I)
Turn
Loosen 2
screws so
screw head is
above clip. DO
NOT Remove Screws
I)
1
Locate spa
locking clips
II)
Slide clip to right until
it stops.
Set panel on ground (go to Step 4)
III)
IV)
Remove panel from spa and place in cool
shaded place
Page 40
Grab locking clip and pull off of door panel
bottom and spa base pan.
Using both hands grab wire
on each side of connector and
pull away from connector.
Service Information
III)
