Activate the clean cycle again to circulate the spa water for another
ten-minute period.
9. ROTATE THE SMARTJET SYSTEM LEVER(S) TO 2ND
POSITION
(9 O'CLOCK) Activate the clean cycle as
described in step 5 to turn on the cycle for ten minutes to circulate
the spa water. Test the spa water for Free Available Chlorine (FAC)
residual. If the residual is between 3 and 5 ppm on the test strips
(between 1 - 5 ppm if using the salt system) go on to the next step. If
the residual is less than 3 ppm, superchlorinate the spa water by
adding 1½ teaspoons of chlorine (sodium dichlor) per 250 gallons
(950 liters) of spa water. Then Activate the clean cycle again to
circulate the spa water for another ten-minute period. Repeat this
procedure until both SMARTJET lever(s) operating positions have
been tested.
G S
ettInG tarted

EQUIPMENT COMPARTMENT DOOR

The equipment compartment door is located below the dock. To remove door, slide each of the 3 clips to the left and lower clip (if clip doesn't slide, slightly
loosen the 2 screws holding the clip). Lower door panel, remove connector from back side of door attached to the Logo light, remove door panel. Reverse
procedure to reattach door panel.
IMPORTANT: Make sure top right side of Logo Light is seated inside spa corner cutout when replacing the door.

EQUIPMENT COMPARTMENT

The illustration below is to be used as a reference only (your spa may look different). The equipment compartment is located behind the front panel of the
spa below the dock.
EQUIPMENT COMPARTMENT
1. Wavemaster
2. No-Fault heater
®
3. Silent Flo 5000
4. IQ 2020 ® control box
Getting Started
1
3
6
® jet pump
® circulation pump
10. RECHECK
the Total Alkalinity (TA) at 80 ppm, Calcium Hardness
(CH) at 100 ppm (if using Salt system between 25 - 75 ppm), then
spa water pH at between 7.4 and 7.8. using a FRESHWATER
5-way test strip.
IMPORTANT: Make sure you adjust your Total Alkalinity first, as
an out-of-balance condition will affect your ability to adjust the pH
correctly, and will prevent the sanitizer from operating effectively.
The spa is ready for use when the spa water has circulated
through each SMARTJET lever operating position and the
chlorine level remains between 3 ppm and 5 ppm.
11. TEST WATER WEEKLY OR BEFORE EACH TIME
THE SPA IS USED.
8
5
5. Ozone injector (optional)
6. Main drain (with shut-off valve)
7. Secondary drain
8. Bonding terminal
Page 7
4
1
2
7
