DOOR PANEL REMOVAL

Use the following instruction to remove the front door panel
below the docking station.
When replacing the door, reverse the order making sure the
Logo is seated in the top right corner of the spa as illustrated
in Step 1.
* 2
Start with clip
A and perform
the following
instructions, then
repeat in order for
steps B and C
* 3
Grab panel on bottom edge and lower
* 4
Disconnect logo light
wire from back side of
door panel
Service Information
English
I)
½ Turn
Loosen
screws ½
turn ONLY.
DO NOT
Remove Screws
I)
Spanish French
* 1
Locate the 3 clips
A,B & C
II)
Slide clip to left until it
stops
Set panel on ground (go to Step 4)
II)
Page 39
A C
B
=
Grab both ends of clip and rotate downward
Remove panel from spa and place in cool
shaded place
III)
