USER MANUAL
This manual applies to systems containing the Hercules Main Processor
and version 9 software
Premier Way, Abbey Park
Romsey, Hampshire, SO51 9AQ
England
Tel: (+44) 01794 518448
Fax: (+44) 01794 518077
www.BandG.com
e-mail: techsupport@BandG.com
© Brookes & Gatehouse Ltd. 2003
The copyright of this Manual is the property of Brookes & Gatehouse Ltd.
HB-0845-05
