Transmission Medium
LED
10BASE-T: 2-pair UTP/STP of Cat. 3,4,5 (maximum 100 m)
(Except SX3206HPP, SG3210XHP-M2, SG3428XF)
100BASE-TX: 2-pair UTP/STP of Cat. 5 or above (maximum 100 m)
1000BASE-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
2.5GBASE-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
(For SX3206HPP, SG3210X-M2, SG3210XHP-M2, SG3218XP-M2,
SG3428X-M2, SG3428XPP-M2)
5GBASE-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
(For SX3206HPP)
10GBASE-T: 4-pair UTP of Cat 6 (maximum 55 m) or STP of Cat 6, 6a, 7
(maximum 100 m) (For SX3206HPP)
100BASE-FX/LX10/BX10: MMF, SMF
(For SG3210, SG3428XF, SG3452, SG3452P)
1000BASE-SX/LX/LX10/BX10: MMF, SMF
10GBASE-SR/LR: MMF, SMF
(For SX3206HPP, SG3210X-M2, SG3210XHP-M2, SG3218XP-M2, SG3428X,
SG3428XF, SG3428XMP, SG3428XMPP, SG3428X-M2, SG3428XPP-M2,
SG3452X, SG3452XP, SG3452XMPP)
10GSFP+CU SFP+ Direct Attach Cable (SM5220-1M, SM5220-3M)
(For SX3206HPP, SG3210X-M2, SG3218XP-M2, SG3428X, SG3428XF,
SG3428XMP, SG3428XMPP, SG3428X-M2, SG3428XPP-M2, SG3452X,
SG3452XP, SG3452XMPP)
SX3206HPP: PWR, SYS, PoE Max, FAN, Speed, PoE, SFP+
SG3210: PWR, SYS, 10/100/1000Mbps, SFP
SG3210X-M2: PWR, SYS, Link/Act, SFP+
SG3210XHP-M2: PWR, SYS, PoE Max, FAN, Speed, PoE, SFP+
SG3218XP-M2: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE
SG3428: PWR, SYS, Link/Act, 1000Mbps, Port 25–28
SG3428MP: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP, Speed, PoE
SG3428X: PWR, SYS, Link/Act, 1000Mbps, Port 25–28
SG3428XF: PWR, SYS, 100/1000Mbps, FAN, SFP+
SG3428XMP: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE
SG3428XMPP: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE
SG3428X-M2: PWR, SYS, FAN, Speed, SFP+
SG3428XPP-M2: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE
SG3452: PWR, SYS, 10/100/1000Mbps, Port 49-52
SG3452X: PWR, SYS, 10/100/1000Mbps, SFP+
SG3452P: PWR, SYS, Speed, PoE Max, FAN, PoE, Port 1-52
SG3452XP: PWR, SYS, PoE Max, FAN, Speed or PoE, Speed, PoE, SFP+
SG3452XMPP: PWR, SYS, PoE Max, FAN, Speed or PoE, Speed, PoE, SFP+
