LED
Indication
On: Running at 1 Gbps, but no activity.
Flashing: Running at 1 Gbps and transmitting or receiving data.
SFP
Off: No device is linked to the corresponding port.
Note: For SG3428MP
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
1000Base-X/
Yellow On: Running at 100 Mbps, but no activity.
100Base-FX
Yellow Flashing: Running at 100 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: For SG3452P
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
SFP+
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: For SG3428XMP/SG3428XMPP/SG3452XP/SG3452XMPP
Console Port
Designed to connect with a computer for monitoring and configuring the switch. When the switch has an
RJ45 console port and a micro-USB console port, console input is active on only one console port at a
time. By default, the micro-USB connector takes precedence over the RJ45 connector.
100 Mbps/1 Gbps/2.5 Gbps/5 Gbps/10 Gbps RJ45 Port
Designed to connect to the device with a bandwidth of 100 Mbps,1 Gbps, 2.5 Gbps, 5 Gbps or 10 Gbps.
For PoE switches, the port can also provide power for PDs.
10 Mbps/100 Mbps/1000 Mbps/2.5 Gbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps,1000 Mbps, 2.5 Gbps. For
PoE switches, the port can also provide power for PDs.
10/100/1000 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps or 1000 Mbps. For PoE
switches, the port can also provide power for PDs.
SFP/SFP+ Slot
SFP slot is designed to install the 1 Gbps SFP module. SFP+ slot is designed to install the 10 Gbps SFP+
module.
Port Feature
Model
SX3206HPP
SX3008F
100 M/1 G/2.5 G/
10 M/100 M/
5 G/10 Gbps
1000 M/2.5 Gbps
RJ45 Port
RJ45 Port
4
/
10/100/1000 Mbps
RJ45 Port
/
/
/
/
Omada L2+ Managed Switch
SFP+ Slot SFP Slot Console Port
2
/
8
/
Introduction
2
2
13
